ASDV Drawbar trailer
Do you want to transport machinery, containers or construction materials efficiently with one versatile transport solution? The Nooteboom ASDV drawbar trailer combines a high payload capacity with a completely flat loadingbed and a robust construction. This makes the ASDV ideally suited for transporting earthmoving equipment, road construction machinery, containers and other heavy loads.
- Nr of Axles 3 to 4
- Suspension Air
- Axle load 10 t/axle
- Load floor height 900 mm
Completely flat and extremely strong loadingbed
A unique feature of the Nooteboom ASDV is its completely flat, continuous loadingbed without a drop section or gooseneck. Thanks to the low construction above the front wheels, the loadingbed can be loaded over its full length, providing maximum loading space. With the main beams positioned on the outside, the ASDV features one of the strongest loadingbeds on the market. This ensures a long service life and maximum reliability, even under intensive use. For the transport of excavators, the trailer can optionally be equipped with an excavator boom recess between the rear axles, further reducing the transport height.
ASDV drawbar trailers
A valuable long-term investment
With the ASDV, you choose a durable and reliable drawbar trailer with low operating costs. The chassis is fully metallised for optimum corrosion protection and a long service life. Thanks to the use of premium A-brand components, you also benefit from maximum reliability and a high residual value.
Tailored to your transport operations
The Nooteboom ASDV drawbar trailer is available with:
- 3 axles (1 front and 2 rear)
- 4 axles (1 front and 3 rear)
- 4 axles (2 front and 2 rear)
- Air suspension with lift/lower function
- Technical axle load of 10 tonnes per axle at 80 km/h
- SAF axles
- Tyre size 235/75R17.5 or 245/70R17.5
- Loaded loadingbed height of approximately 900 mm
- Drawbar and loadingbed in various lengths
- Loadingbed width of 2540 mm
- Fold-out loadingbed widening
- Extensive range of loading ramps with a low loading angle
- Various toolboxes and storage compartments
- Excavator boom recess between the rear axles
- Removable container guides
The reliable choice for machinery and material transport
Whether you transport earthmoving equipment, road construction machinery, containers or construction materials, the Nooteboom ASDV provides a robust drawbar trailer that combines maximum loading space, flexibility and durability for daily heavy transport operations.
